Yli 100 vuotta pyöräilyn DNA:ta. Perheemme edustaa rohkeutta, kokemusta ja visiota - ominaisuuksia, jotka näkyvät jokaisessa Raymon-pyörässä. Tämän perinteen pohjalta luomme pyöriä, jotka tarjoavat juuri sen, mitä etsit maantiellä ja maastossa.
Polkupyörän tekniset tiedot
Sähköpyöräjärjestelmä
Moottori:
Bosch Performance Line CX, 250/600 W, 85 Nm
Pyörätietokone:
Bosch LED Remote, Bluetooth
Kaukosäädin:
Bosch Kiox 300
Akku:
Bosch PowerTube, 800 Wh, 36 V
Laturi:
Bosch Charger, 4 A
Runko ja ripustus
Runko:
Aluminium 6061, removeable battery, boost
Haaruka:
RockShox Recon Gold RL, air, 80 mm, tapered
Voimavoima
Takavaihtaja:
Shimano Deore XT, RD-M8100, Shadow Plus, 12-speed
Vaihdevivut:
Shimano Deore, SL-M8100, Rapidfire Plus
Kampisarja:
Raymon, Narrow Wide, 40T, CG
Kasetti:
Shimano CS-M7100, 10-51T
Jarrujärjestelmä
Jarrut:
Shimano BR-M8120, 4-piston, Hydraulic Disc
Ohjaustankojärjestelmä
Ohjaustanko:
Raymon Riser 31,8 mm, Sweep: 15 °, Rise: 30 mm
Ohjainkannatin:
Raymon 31.8, Ahead, adjustable
Kädensijat:
Raymon Ergo, lock on
Ohjainlaakeri:
FSA CR, Internal Cable Routing
Pyörät
Polkupyörän pyöräsarja:
Raymon VR24/DT210, 15x110/12x148 mm
Eturengas:
Schwalbe Marathon E-Plus, Reflex, 55-622, 29x2.15
Renkaat:
Schwalbe Marathon E-Plus, Reflex, 55-622, 29x2.15
Satula ja komponentit
Satula:
Raymon MIMA VM fit
Satulatolppa:
Raymon, 34,9 mm, Dropper Post
Satulatolpan kiristin:
38,9, hex screw
Lisävarusteet
Seisontatuki:
Ursus MOOI, KSA40, adjustable
Tavarateline taka:
Raymon, MIK HD, 27 kg
Etuvalo:
Litemove SEC-150, 150 lx
Paino ja mitat
Suurin kuormitus (pyörä+pyöräilijä):
150 kg
The Performance Line CX takes riding dynamics and agility to a whole level. It is powerful, light and quiet. Ten years of experience and countless trail rides all over the world have gone into its further development. The Performance Line CX combines power, dynamics, efficiency and altitude. 85-600-340: These values represent the ideal balance between performance and riding fun in relation to wear and range. 85 Nm Max. Torque; 600 W Max. motor power; 340 % Max. support factor.
