Product technical specifications
- Crank arm length: 170 mm
- Bottom bracket axle profile: 24mm Hollow Shaft
- Bottom bracket case width: 68 mm, 70 mm
- Chain line: 50 mm
- Q-factor: 152 mm
- Bolt Circle Diameter (B.C.D.): 110 mm
- Rear Speeds: 9/10/11-speed
- Gear Combination: 40T
- Recommended bottom bracket (not included): Press-Fit BB-RS500-PB
- Recommended bottom bracket (not included): Threaded BB-RS501
- Compatible bottom bracket type Outboard
- Compatibility chain: CN-HG901-11, CN-HG701-11, CN-HG601-11, CN-LG500
- Material: Crank Arms, Spider - Aluminum (painted), Chainring - Steel (anodized), Axle: - Steel (plated )
TECHNOLOGIES
DYNAMIC CHAIN ENGAGEMENT+ - It gives more chain retention and smoother pedaling - even over bumpy terrain. Chain retention of any gear will reduce abrasion and worn out.
HOLLOWTECH II - Providing the best balance of stiffness, strength, weight and rotating performance. The concept of HOLLOWTECH II technology is focused on producing a superior crankset which will maximize a riders power transfer. The rigidity of the crankset ensures pedaling efficiency while its weight, a key element of the crankset, you want light, aids in cycling longer distances over which the rider needs to pedal more. HOLLOWTECH technology is an ultra-lightweight hollow crankarm created by SHIMANO with the companys own proprietary forging technology that also maintains rigidity. The addition of HOLLOWTECH II technology integrates the bottom bracket axle with the right crankarm for more stiffness and a weight savings to achieve a high-dimensional balance. Its outboard bottom bracket bearing system provides better weight distribution and more pedaling stability, allowing for more efficient power transfer.
- Tuotteen nimi
- Kampisarja Shimano CUES FC-U6040-1 170mm 9/10/11-speed
- Tuotekoodi
- EFCU60401CXB0X
- Valmistajat
- Shimano
- Viivakoodi
